Havells Single core wire 1mm Earthing wire (yellow-green) PVC flexible cable 100 Yards
AED 49.35 Incl. VAT
Technical Specifications
Voltage: 600/1000V
Nominal Cross Section – sq. mm : 1
Conductor Construction (nos./ Dia.) (mm): 32/0.2*
DC Resistance at 20°C (Ohm/Km): 19.5
Approx. Net Weight (Kg/Km): 0.8
Approx Overall Diameter (mm): 2.8
Current Carrying Capacity (Amp): 14
Length per roll (meters): 91.44
Standard conformity: CE
- Description
- Additional information
- Reviews (0)
- Technical Reference
Description
Description
Buy Havells wire 1mm Earthing wire ( yellow-green)| Single core cables | Flexible cables | PVC cables
HAVELLS 600/1000V HR PVC INSULATED FLEXIBLE WIRE AS PER BS 6231
Conductors
• Plain annealed copper conductor, high conductivity
• 0.50mm2 to 150mm2 flexible copper complying with BS6360 Class 5.
Insulation
• PVC insulation complying with BS7655 requirements for type T13, Suitable for operation – 15°C to 105°C Core Identification
• RED, BLACK, BLUE, YELLOW, YELLOW/GREEN Colour or other colours available on request.
Harmonized Code Designation
• Upto 1.00mm2 flexible wire H05V2-K
• From 1.5mm2 to 300mm2 flexible wire H07V-K
Additional information
Additional information
| Weight | 0.8 kg |
|---|---|
| Color | |
| Primary Current | |
| Secondary Cuurent | |
| Country of Origin | India |
| Product Type | Cables |
| Switchgear Category | Cables and Insulation |
